Description
F-Link 4 Relay Expansion Unit. The F-Link 4 Relay Expansion unit is used to indicate on the master alarm panel which remote F-Link node has entered an alarm state.
Standard features:
- 15 switched relay outputs notify the Master Fire Panel which F-Link has gone into alarm
- Power input common with the F-Link 4 (12-24V dc)
- Data cable included for connection to Master F-Link unit
- Configuration software assigns each relay to an F-Link node for notifying a “Fire” event
- Alternative configuration allows both “Fire” and “Fault” events for up to 7 nodes
- XP30 unit (30 relays) allows both “Fire” and “Fault” events for all 15 nodes
